174 x 156 x 87 cm
119 Kg
310 mm support brackets for 8 Bodytone discs of 20 kg per arm (up to 280 kg for training). 2 supports for storage of 4 Bodytone discs of 20 kg per side.
Our machines are designed for a very broad spectrum of users, allowing the regulation of them to adapt to different user statures, from 150 to 200 cm approximately.
110x52 mm Steel pipe, 3 mm thick as per UNE EN 10219, quality s-275-J0H. Enriched and optimized to maintain a constant section in the bending process, avoiding fragile areas with low breakage rate. Cold bending process by 4-roller system to avoid deformation during the process, keeping its physical characteristics throughout the piece.
3 layers of paint. Steel pickling and stabilized by immersion of the parts in different degreasing solutions to ensure a perfect and complete cleaning of the base material. Antioxidant primer to ensure adquate isolation of internal oxidation and good paint adhesion. 2 final coats of epoxy paint.
Ergonomic and biomechanical study under our associated professional athletes. After a long design process; from the drawing of the sketch, prototypes making and tested by athletes our products are released to the market.
Perimeter closing welding in structural points and union plates.
10 mm plate-against Plate system, to avoid looseness and torsion in maximum effort areas. Ergonomic and biomechanical research optimized for every exercise.
10 mm thickness plates cut by laser with another 10 mm plate for reinforcement,for a smooth movement withour looseness or torsion produced for the continouos usage or loading.
SFK double tapared roller bearing, allocated in closed bushing ensuring a constant direction movement.
Double grip to facilitate different types and angles of exercise. Double disc holder for heavier exercises. Handles in anodized aluminum, knurled favoring grip.
Plate supports made in burnished steel, providing more stability to the machine. Turned Aluminium endings. Screw hardness 10.9. Regulation system by a single bolt made of techno polymer with 750 shear rate. 4 non-slip rubber bases.
